Fields in Forms Matrix

When cleaning up existing applications it is good to have an overview what fields are used across forms. Unfortunately the synopsis isn't very helpful there. However with a few lines of LotusScript one can create a matrix that serves as an overview. It is a comparison by name only and doesn't tell you anything about computation mode or data-type. But it is a start. YMMV



  'CreateFieldMatrixReport:

  Option

  Public

  Option

  Declare

  Dim fieldList

  List

  As

  Integer

  'The row for a specific field name

  Dim fieldCount

  As

  Integer

  'How many unique fieldnames do we have 0 based

  Sub

  Initialize

  Dim db

  As

  NotesDatabase

  Dim s

  As

  New

  NotesSession

  Dim out

  As

  NotesStream

  Dim curForm

  As

  NotesForm

  Dim filename

  As

  String

  Dim formList

  List

  As

  Variant

  'A list with arrays of fiields

  Dim formCount

  As

  Integer

  'How many forms do we have 0 based

  Dim fieldArray

  (

  )

  As

  Boolean

  On

  Error

  Goto Err_Initialize

 fileName

  =

  Inputbox

  (

  "Where to store the result"

  )

  If fileName

  =

  ""

  Then

  Exit

  Sub

  End

  If

  Set out

  = s

  .CreateStream

  Call out

  .

  Open

  (fileName

  )

  Call out

  .Truncate

 formCount

  =

  -1
 fieldCount

  =

  -1

  Set db

  = s

  .CurrentDatabase

  'Extract all the fields and forms

  Forall f In db

  .Forms
  formCount

  = formCount

  + 1

  Set curForm

  = f
  formList

  (curForm

  .

  Name

  )

  = curForm

  .Fields

  Call extractFields

  (curForm

  .Fields

  )

  End

  Forall

  'Now size the array

  Redim fieldArray

  (fieldCount

  ,formCount

  )

  'Header
 out

  .WriteText

  (

  |<html><head><title>Field Matrix</title></head><style>.yes {background-color : red; color : white }|

  )
 out

  .WriteText

  (

  | .no { color : white} table {width : 100%} td {text-align : center}</style></head><body><table>|

  )

  'Now fill the array

  Dim i

  As

  Integer

  Dim j

  As

  Integer

  'Now fill the array and the first table
 out

  .WriteText

  (

  |<tr><th>Field/Form</th>|

  )
 i

  =

  -1

  'Reset i as Rowcounter

  Forall curFields In formList
  i

  = i

  + 1

  For j

  = 0

  To

  Ubound

  (curFields

  )
   fieldArray

  (fieldList

  (curFields

  (j

  )

  )

  ,i

  )

  =

  True

  Next

  Call out

  .WriteText

  (

  |<th>|

  )
  out

  .WriteText

  Listtag

  (curFields

  )

  Call out

  .WriteText

  (

  |</th>|

  )

  End

  Forall

  Call out

  .WriteText

  (

  |</tr>|

  )

  'Now the matrix in its full beauty

  Forall curFields2 In FieldList
  out

  .WriteText

  (

  |<tr><td>|

  +

  Listtag

  (curFields2

  )

  +

  |</td>|

  )

  'curFields2 has the row, we loop through the columns

  For j

  = 0

  To formCount

  If fieldArray

  (curFields2

  ,j

  )

  Then

  'it is boolean after all
    out

  .WriteText

  (

  |<td class="yes">+</td>|

  )

  Else
    out

  .WriteText

  (

  |<td class="no">-</td>|

  )

  End

  If

  Next
  out

  .WriteText

  (

  |</tr>|

  )

  End

  Forall

  'Footer
 out

  .WriteText

  (

  |</table></body></html>|

  )

Exit_Initialize

  :

  On

  Error

  Resume

  Next

  Call out

  .

  Close

  Exit

  Sub

Err_Initialize

  :

  Msgbox

  Error$

  Resume Exit_Initialize

  End

  Sub

  Sub extractFields

  (allFields

  As

  Variant

  )

  'fieldList, fieldcount are globla

  Forall curFieldName In allFields

  If

  Not

  Iselement

  (fieldList

  (curFieldName

  )

  )

  Then

  'We only add fields we don't have in the list
   fieldcount

  = fieldCount

  + 1
   fieldList

  (curFieldName

  )

  = fieldCount

  End

  If

  End

  Forall

  End

  Sub

This LotusScript was converted to HTML using the ls2html routine,
provided by Julian Robichaux at nsftools.com.

Posted by Stephan H Wissel on 15 September 2008 | Comments (3) | categories: Show-N-Tell Thursday

posted by Marius Neumann on Monday 15 September 2008 AD:
Thanks for the nice piece of code. Its working fine here!

Unfortunately, for me it's usually not sufficient to search for forms when it comes to cleaning up or renaming Notes fields. I prefer searching then whole DB design, e.g. with a free tool like this one: { Link }

posted by Theo Heselmans on Monday 15 September 2008 AD:
Very interesting. Tx Stephan

posted by Kevin Pettitt on Monday 15 September 2008 AD:
Great idea Stephan. Certainly a good free option. You can get a similar data using one of the "Design views" in SuperNTF, which shows all fields categorized by Form/Subform.

However, I normally use Teamstudio Analyzer for this, which does provide information about datatype, and I even created a custom view for the Analyzer template to show more of this detail. You can download my "Analyzer Plus" custom views from OpenNTF here: { Link }

One idea for enhancing this general technique here would be to parsing the form DXL, which also provides datatype and fieldtype detail (and much more). For example:

<field type="text" kind="editable" name="Form" allowmultivalues="false" protected="false" sign="false" computeaftervalidation="false" defaultfocus="false" showdelimiters="true" allowtabout="false" useappletinbrowser="false" storelocally="false" dataconnectionfield="data">
