10 Commandments for public facing web applications

A customer recently asked how a public facing web application on Domino would be different from an Intranet application. In general there shouldn't be a difference. However in a cost/benefit analysis Intranets are usually considered "friendly territory", so less effort is spent on hardening against attacks and poking around (much to my delight, when I actually poke around). With this in mind here you go (in no specific order):
  1. Protect your server: Typically you would have a firewall and reverse proxy that provides access to your application.
    It should be configured to check URLs carefully to ensure no unexpected calls are made from somebody probing database URLs. It is quite some work to get that right (for any platform), but you surly don't want to become "data leak" front-page news.
    There's not much to do on the Domino side, it is mostly the firewall guys' work. Typical attack attempts include stuff like ?ReadViewEntries, $Defaultxx or $First. Of course when you use Ajax calls into views you need to cater for that.
    I would block *all* ?ReadViewEntries and have URL masks for the Ajax calls you plan to use. Be careful with categorized views. Avoid them if possible and always select "hide empty categories". Have an empty $$ViewTemplateDefault that redirects to the application
  2. Mask your URLs: Users shouldn't go to "/newApp/Loand2013/loanapproduction.nsf?Open" but to "/loans". Use Internet site documents to configure that (eventually the firewall/reverse proxy can do that too). In Notes 9.0 IBM provides mod_domino, so you can use the IBM HTTP Server (a.k.a Apache HTTP) to front Domino. On the XPagesWiki there is more information on securing URLs with redirects. Go and read them
  3. Harden your agents: Do not allow any ?OpenAgent URL (challenge: an agent also opens on ?Open, so if all agents have a certain naming you can use URL pattern to block them). In an agent make sure your code handles errors properly. Check where the call to an agent came from. If it was called directly discard it.
  4. Treat data with suspicion: Do not rely on client side validation. Providing it is nice for the user as comfortable input aid. However you don't control the devices and browsers anymore and an attacker can use Firebug or CURL to bypass any of your validations. You have to validate everything on the server (again). Also you have to check content for unexpected input like passthru HTML or JavaScript. XPages does that for you
  5. Know your user: Split your application into more than one database. One for the publicly accessible content (access anonymous) and one that requires authentication. Do not try to dodge authenticated users and re-invent security mechanisms. You *will* overlook something and then your organisation makes headline news in the "latest data breach" section. There are ample examples how to generate LTPA tokens outside of Domino, so you don't need to manage usernames/passwords etc if you don't want to. Connect them to your existing customer authentication scheme (e.g. eBanking if you are a bank) for starters. Do not rely on some cookie you try to interpret and then show or don't show content. The security tools at your hand are are ACL and reader fields
  6. Test, Test, Test: You can Usability test, load test, functional test, penetration test, validity test, speed test and unit test. If you don't test, the general public and interested 3rd parties will do that for you. The former leads to bad press, the later to data breaches
  7. Use a responsive layout: Use the IBM OneUI (v3.0 as of this blog date) or Bootstrap (get a nice theme). XPages provides great mobile controls. Using an XPage single page application you can limit the range of allowed URLs to further protect your assets
  8. Code for the most modern browser: use HTML5 and degrade gracefully. So it is not "must look the same in all browsers", but "users must be able to complete tasks in all browsers" - experienced might differ. Take advantage of local cache (use an ETag and all the other tips!)
  9. Use https the very moment a user is known. If in doubt try Firesheep
  10. Of course the Spolsky Test applies here too!
As usual YMMV
